Heavy Duty CNC Stone Router

Name: Heavy Duty CNC Stone Router
Brand: Wanneng Trading Company
Price: 250000.0 INR
Availability: InStock

Price 250000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Heavy Duty CNC Stone Router Specification

Product Type
CNC Stone Router

General Use
Stone Engraving, Marble/Granite Cutting

Material
Cast Iron, Steel, Aluminum Components

Type
Heavy Duty CNC Router

Capacity
3000 x 2000 mm working area

Weight (kg)
2500 kg

Computerized
Yes

Automatic
Yes

PLC Control
Available

Power Source
Electric

Power Consumption
7.5 kW

Rigidity
Heavy Duty

Voltage
380V / 415V

Motor
High Precision Servo Motor

Table Size
2000 mm x 3000 mm

Spindle Speed
0-24000 RPM

Axial Choice
3 Axis (optional 4th/5th Axis)

Dimension (L*W*H)
3650 mm x 2200 mm x 2100 mm

Feature
High Stability, Accurate Carving, Water Cooling Spindle

Color
Blue-White

Warranty
1 year

Workholding
Vacuum Table (Optional)

Dust Protection
Available

Control System
NC Studio / DSP / Mach3 (Selectable)

Spindle Power
5.5 kW to 7.5 kW

Drive Type
Rack and Pinion

Max Moving Speed
35 m/min

Resolution
0.01 mm

Cooling System
Water Cooling

Compatible Software
ArtCAM, UG, Type3, JD Paint, etc.

Lubrication System
Automatic Central Lubrication

Table Structure
T-Slot/Waterbed

Guide Rail
Linear Guide Rail

Heavy Duty CNC Stone Router Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
1 Piece Per Week

Delivery Time
3 Days

Packaging Details
Wooden Box/Pallet Packing.

Main Domestic Market
Delhi, Bihar, Uttar Pradesh, Himachal Pradesh, West Bengal, Chhattisgarh, Punjab, Haryana, Rajasthan, Jharkhand, Jammu and Kashmir, Uttarakhand

About Heavy Duty CNC Stone Router

To catch up the colossal recognition among global clients, we put forth a wide spectrum of Heavy Duty CNC Stone Router. This is manufactured by our adroit professionals using top notch quality components and latest techniques under the observation of our experts. Offered router is highly appreciated due to its computer controlling and used for cutting the stones at a very large scale. Our valuable clients can availed the provided Heavy Duty CNC Stone Router from us at cost effective prices.

Keypoints:

High strength
Excellent efficiency
Longer service life
Simple to operate

Superior Precision and Reliability

Built on a robust cast iron frame and equipped with linear guide rails, this CNC stone router guarantees remarkable stability and vibration resistance. Its water-cooled spindle and advanced dust protection system ensure longevity and reliability in even the most demanding industrial settings.

Versatile Application and Ease of Operation

Capable of intricate engraving on stone, marble, and granite, this router accommodates a range of creative and functional tasks. The selectable control systems and compatibility with popular design software make it user-friendly for both experienced operators and newcomers.

Optimized for Productivity and Safety

With features like the automatic central lubrication and heavy-duty rack and pinion drive, this machine minimizes maintenance while maximizing uptime. The optional vacuum table and comprehensive dust protection contribute to a cleaner, safer work environment for operators.

FAQ's of Heavy Duty CNC Stone Router:

Q: How does the linear guide rail system benefit CNC stone routing operations?

A: The linear guide rail system provides smooth, precise motion and minimizes friction, resulting in highly accurate carvings and stable performance even during heavy-duty operation. It also increases the lifespan of mechanical components.

Q: What types of materials can this CNC router process?

A: This machine is expertly designed for stone materials such as marble and granite but can also handle materials like cast iron, steel, and aluminum components for specialized applications.

Q: When should the central lubrication system be engaged, and how does it work?

A: The automatic central lubrication system operates at set intervals during machine use, ensuring continuous lubrication of critical moving parts. This reduces wear and maintenance, extending the service life of the machine.

Q: Where can this CNC router be effectively installed?

A: Given its industrial size and weight (2500 kg), the router is best installed in spacious workshops or manufacturing facilities with a reliable 380V/415V power source and appropriate floor support for its dimensions.

Q: What is the typical process for engraving or cutting stone using this CNC router?

A: First, a digital design is created using compatible software such as ArtCAM or UG. The file is sent to the control system (NC Studio, DSP, or Mach3), and the machine automatically follows the program to engrave or cut the stone per specifications. The water cooling and dust protection systems operate throughout to maintain optimal conditions.

Q: How does the optional vacuum table enhance workpiece holding during machining?

A: The optional vacuum table securely holds flat stone substrates in place during cutting or engraving, minimizing movement and improving overall machining precision and surface quality.

Q: What are the primary benefits of choosing this heavy-duty CNC stone router for industrial stone engraving?

A: Benefits include exceptional carving accuracy (resolution: 0.01 mm), high spindle speed (up to 24,000 RPM), reliable heavy-duty construction for stability, reduced manual labor through automation, and compatibility with leading design software for seamless workflows.
